VTC80 Turing Center with 12 Post Driven Turret and SIEMENS 828D

VTC80 Turing Center with 12 Post Driven Turret and SIEMENS 828D with SIEMENS 828D Basic Control System; Turret rotary motor is DELTA; 12 Post Driven Tool Turret(BMT65); A2-15,Hydraulic Solid Chuck 21inch; Chip conveyor; No Tailstock.

VTC80 Turing Center with 12 Post Driven Turret and SIEMENS 828DDownload

INQUIRY

PDF Format

Description

Specifications

Features

COMPONENT LIST

VTC80 Turing Center with 12 Post Driven Turret SIEMENS 828D Specifications

Configuration		VTC80
Machining Capacity	Maximum Swing Over Bed ø/mm	900
	Max Machining Height mm	650
	Max Machining Diameter ø/mm	800
Spindle	Spindle Type	A2-15
	Spindle Speed Range r/min	50-1200
	Spindle Shift Mode	Servo
	Main Motor Power kW	22
	Chuck Type	Hydraulic Solid
	Chuck Size inch	21"
Feed Rate	Rapid Traverse Speed On X-axis m/min	25
	Rapid Traverse Speed On Z-axis m/min	25
	Servo Motor Torque On X-axis Nm	18
	Servo Motor Torque On Z-axis Nm	22
	X-axis Travel mm	550
	Z-axis Travel mm	700
	Guideway Type	Roller Guideway
Turret	Turret Type	12 Post Driven Tool Turret (BMT65)
Turret	Turning Tools /Boring Bar Size mm	25*25 / ø40 / ER40
Power Source	Total Rated Power KVA	36
	Total Rated Current A	73
	Voltage V	AC380
	Voltage Range	-10～+10%
	Frequency Hz	50±1
Dimension	Machine Weight KGS	9000
Dimension	Machine Dimension LWH(mm)	1900×2200×3100

Main Feature
1-Tool Box,Work Lamp,Color Light,Auto Lubrication System,Full metal sheet cover;
2-Heat exchanger for control cabinet,Coolant Pump,Control System &Machine Manual(all language is ENGLISH);
3-12 Post Driven Tool Turret(BMT65);
4-A2-15,Hydraulic Solid Chuck 21inch;
5-Chip conveyor;
6-No Tailstock.

VTC80 Turing Center with 12 Post Driven Turret SIEMENS 828D COMPONENT LIST
No.	Parts Name	Model	Supplier
1	Control System	SIEMENS 828D Basic	SIEMENS
2	Servo Motor	X:20Nm	SIEMENS
2	Servo Motor	Z:20Nm	SIEMENS
3	Spindle Motor Power	22kw	SIEMENS
4	Spindle Bearing	NN3040
5	Spindle Bearing	NN3032
6	Spindle Bearing	234440
7	Ball Screw	X: 4012	THK
7	Ball Screw	Z: 5012	THK
8	Ball Screw Bearing	X: 30TAC62 DB	NACHI
8	Ball Screw Bearing	Z: 40TAC90 DB	NACHI
9	Turret	12 Post Driven Tool Turret(BMT65)	TAIWAN SWIFT
10	Chuck	Hydraulic Solid Chuck 21inch	KEPUTE
11	Auto Lubrication Unit	XY3.5P-CBBXK-ZCAG	CNP
12	Coolant Pump	LIC2-5015P	LEO
13	Working Light	470L	AOTENG
14	Foot Pedal	N/A	TAIZHOU EASTERN
15	Safety Relay 1pc	N/A	OMRON

VTC80 Turing Center with 12 Post Driven Turret SIEMENS 828D Specifications

Configuration		VTC80
Machining Capacity	Maximum Swing Over Bed ø/mm	900
	Max Machining Height mm	650
	Max Machining Diameter ø/mm	800
Spindle	Spindle Type	A2-15
	Spindle Speed Range r/min	50-1200
	Spindle Shift Mode	Servo
	Main Motor Power kW	22
	Chuck Type	Hydraulic Solid
	Chuck Size inch	21"
Feed Rate	Rapid Traverse Speed On X-axis m/min	25
	Rapid Traverse Speed On Z-axis m/min	25
	Servo Motor Torque On X-axis Nm	18
	Servo Motor Torque On Z-axis Nm	22
	X-axis Travel mm	550
	Z-axis Travel mm	700
	Guideway Type	Roller Guideway
Turret	Turret Type	12 Post Driven Tool Turret (BMT65)
Turret	Turning Tools /Boring Bar Size mm	25*25 / ø40 / ER40
Power Source	Total Rated Power KVA	36
	Total Rated Current A	73
	Voltage V	AC380
	Voltage Range	-10～+10%
	Frequency Hz	50±1
Dimension	Machine Weight KGS	9000
Dimension	Machine Dimension LWH(mm)	1900×2200×3100

Main Features:
1-Tool Box,Work Lamp,Color Light,Auto Lubrication System,Full metal sheet cover;
2-Heat exchanger for control cabinet,Coolant Pump,Control System &Machine Manual(all language is ENGLISH);
3-12 Post Driven Tool Turret(BMT65);
4-A2-15,Hydraulic Solid Chuck 21inch;
5-Chip conveyor;
6-No Tailstock.

VTC80 Turing Center with 12 Post Driven Turret SIEMENS 828D COMPONENT LIST
No.	Parts Name	Model	Supplier
1	Control System	SIEMENS 828D Basic	SIEMENS
2	Servo Motor	X:20Nm	SIEMENS
2	Servo Motor	Z:20Nm	SIEMENS
3	Spindle Motor Power	22kw	SIEMENS
4	Spindle Bearing	NN3040
5	Spindle Bearing	NN3032
6	Spindle Bearing	234440
7	Ball Screw	X: 4012	THK
7	Ball Screw	Z: 5012	THK
8	Ball Screw Bearing	X: 30TAC62 DB	NACHI
8	Ball Screw Bearing	Z: 40TAC90 DB	NACHI
9	Turret	12 Post Driven Tool Turret(BMT65)	TAIWAN SWIFT
10	Chuck	Hydraulic Solid Chuck 21inch	KEPUTE
11	Auto Lubrication Unit	XY3.5P-CBBXK-ZCAG	CNP
12	Coolant Pump	LIC2-5015P	LEO
13	Working Light	470L	AOTENG
14	Foot Pedal	N/A	TAIZHOU EASTERN
15	Safety Relay 1pc	N/A	OMRON
