Why buyers choose this configuration
Gantry design with wide column spacing
Handles large plates and weldments without sacrificing floor space.
High spindle torque for heavy cutting
Removes material fast on large surfaces, cutting cycle times.
Rigid structure for precision on big parts
Maintains accuracy across long travels, reducing scrap and rework.
Large work envelope for oversized parts
Eliminates need for multiple setups or outsourcing large components.
Fast traverse rates for quick positioning
Shortens non-cutting time, improving overall productivity.
Specifications (42 items from the manufacturer's catalogue)
| Column span | 2600 mm |
| Table width | 2000 mm |
| No. of tools | 24 |
| Rotary table | mm |
| Table length | 3000 mm |
| Spindle speed | 18000 r/min |
| X axis travel | 3000 mm |
| Y axis travel | 1000 mm |
| Z-axis travel | 1000 mm |
| Control system | SIEMENS 828D (FANUC 0i- MF) |
| Machine weight | 22000 kg |
| Worktable load | 5000 kg |
| Worktable size | 2000x3000 mm |
| Max. out torque | 35/42 N.m |
| Tool shank size | HSK-A63 |
| Worktable width | 2000 mm |
| X-axis travel (mm) | 3000 |
| Y-axis travel (mm) | 2000 |
| Z-axis travel (mm) | 1000 |
| Columns distance | 2600 mm |
| Worktable length | 3000 mm |
| Tool shank specification | HSK-A63 |
| Axis travel X/Y/Z | 3000x2000x1000 mm |
| A/C indexing angle | ±110/±200 ° |
| Max. output torque | 35/42 N.m |
| Max. spindle speed | 18000 r/min |
| Spindle motor power | 20/23.5 kW |
| Spindle terminal to | 200-1200 mm |
| Table load capacity | 5000 kg |
| Rapid traverse X/Y/Z | 60/60/48 m/min |
| Table width (mm) | 2000 |
| Table length (mm) | 3000 |
| Max. speed (r/min) | 18000 |
| A/C-axis indexing angle (°) | ±110/±200 |
| Distance between columns (mm) | 2400 |
| Spindle motor power (kW) | 20/23.5 |
| Max. output torque (N.m) | 35/42 |
| Rotary table load capacity | kg |
| Max. tool dia./length/weight | Φ80/300/7 mm/mm/kg |
| Spindle end to table surface | 200-1200 mm |
| Max. tool dia. (no adjacent tool) | Φ150 mm |
| Spindle end to rotary table center | mm |
Where it earns its keep
Large steel plates for construction equipment
Weldments for agricultural machinery frames
Medium-to-large mold bases and dies
Aerospace structural components like spars and ribs
Large aluminum parts for industrial machinery
Heavy-duty pump and valve housings
Machine tool tables and bases
Large gearbox casings
Warranty & after-sales
Fortune Pacific is the contracting promisor for this SKU.
2-year warranty for manufacturing defects; first technical reply within 24 business hours.
Support requests are handled through Fortune Pacific as the export-window counterpart.
